TOYOTA PRIUS XW20 (2003-2009) SERVICE WORKSHOP MANUAL

TOYOTA PRIUS XW20 (2003-2009) SERVICE WORKSHOP MANUAL IN PDF FORMAT (4721 PAGES) SUPPLIED AS DOWNLOADABLE LINK .

Powertrain

Engine. Toyota Hybrid System II

Gasoline:

1.5 L Atkinson Cycle 1NZ-FXE DOHC I4 VVT-i[3]

57 kW (76 hp) @ 5000 rpm

115 N·m (85 lb·ft) @ 4200 rpm

Electric:

50 kW (67 hp) @ 1200 rpm

400 N·m (295 lb·ft) @ 0 rpm

AT-PZEV

Hybrid system net horsepower: 110 hp (82 kW)

Transmission1-speed planetary gearHybrid drivetrainPower-split hybrid
